Intended use
The product is suitable for pancreaticobiliary system intubation and sphincterotomy.
Product Features
◎ Zebra guide wire can be pre installed for easy operation.
◎ The cutter head is pre bent and shaped so that the cutter head faces 11 o'clock.
◎ The conical and round knife tip has small intubation resistance, which is convenient for inserting into the bile duct, and the damage to the nipple tissue during intubation is small.
◎ The cutter head direction can be adjusted to facilitate nipple intubation and superselection of left and right hepatic ducts.
◎ Semi insulating coating can be selected at the rear end of wire cutting to prevent excessive cutting.
◎ Ergonomic handle and joint design, good hand feeling and convenient operation.
| Part No. | Bow Knife | Compatible Thread | Length Of Cutting | Working Length (mm) | Channel (mm) | Triple Lumen |
| SD-07-A20 | TYPE A | 0.035” | 20 | 2000 | 2.8 | Triple |
| SD-07-A25 * | TYPE A | 0.035” | 25 | 2000 | 2.8 | Triple |
| SD-07-A30 | TYPE A | 0.035” | 30 | 2000 | 2.8 | Triple |
| SD-07-B20 | TYPE B Rapid Exchange | 0.035” | 20 | 2000 | 2.8 | Triple |
| SD-07-B25 | TYPE B Rapid Exchange | 0.035” | 25 | 2000 | 2.8 | Triple |
| SD-07-B30 | TYPE B Rapid Exchange | 0.035” | 30 | 2000 | 2.8 | Triple |
| SD-07-C05 | TYPE C With Needle | 0.035” | 5 | 2000 | 2.8 | Triple |
