YG101
Product Function
◎ Aluminum shell/Large space wind proof cover
◎ LCD（White back light with black font）
◎ Tare function
◎ Overload alarm/Level indicator
◎ Interface RS232/Printer
◎ Date/Time/Number of samples set
◎ Automatically store 200 data/Delete and continuation
◎ Inquiry/Print: Testing date,time,checker,number of machinery,the distribution of raw silk size,hank number,sum,average raw silk size,silk size diviation,mean square diviation,maximum diviation
| Model | YG101 |
| Capacity | 110g(99.5D) |
| Readability | 0.001g(0.5D) |
| Min Weighing | 0.004g |
| Repeatability | ±0.002g |
| Linearity | ±0.003g |
| Pan Size | φ90mm |
| Draft Shield Size | 240×190×265mm |
| Communication | RS232 |
| Temperatur | 5-25℃ |
| Cal.Weight | 100g |
| Packing Size | 465x315x660mm |
| Gross Weight | 9kg |
Y871
Product Function
◎ LED（Green）
◎ Tare function/Counting
◎ Overload alarm
◎ Option: Under weighing/Interface/Printer
◎ Number of samples set
◎ Display: G (g) / Dan Neal value (D) (size value)
| Model | Capacity | Readability | Min weighing | Pan Size | Temperatur | Cal.Weight | Packing Size | Gross Weight |
| Y871 | 110g(99.5D) | 0.001g(0.5D) | 0.004g | φ130mm | 5-25℃ | 100g | 310×230×155mm | 3kg |
JA203SD
Product Function
◎ Aluminum shell/Large space wind proof cover
◎ LCD(White back light with black font)
◎ Tare function
◎ Overload alarm/Level indicator
◎ Interface RS232/Printer
◎ Unit conversion: OZ/Tex/Nm/Ne/D/g/m2/oz/yd2
◎ Date/Time/Number of samples/Yarn blend codeset
◎ Automatically store 100 data/Delete and continuation
◎ Statistics/Print: Each weighing value,Maximum value(Max),Minimum value(Min),Average (AV),Uneven rate (CV)
| Model | Capacity | Readability | Min Weighing | Repeatability | Linearity | Linearity | Draft Shield Size | Communication | Temperature | Cal.Weight | Packing Size | Gross Weight |
| JA203SD | 210g | 0.001g | 0.004g | ±0.002g | ±0.003g | φ90mm | 240×190×265mm | RS232 | 5-25℃ | 200g | 465×315×660mm | 9kg |
XY-2CS
Product Function
◎ LCD（White back light with black font）
◎ AC and DC power supply
◎ Tare function/Counting/Unit conversion(gsm/g/ct/oz)...
◎ Overload alarm/Level indicator
◎ Option: Dual display/Interface/Printer
| Model | Capacity | Readability | Min Weighing | Pan Size | Temperatur | Cal.Weight | Packing Size | Gross Weight |
| XY200-2CS | 210g | 0.01g | 0.04g | φ130mm | 5-25℃ | 200g | 310×230×155mm | 2.5kg |
| XY300-2CS | 310g | |||||||
| XY500-2CS | 510g | |||||||
| XY1000-2CS | 1100g | 500g |
