Standard: static eliminator
Product Function
◎ Automatic Internal Calibration
◎ 5 Inch Touch Screen
◎ Automatic Internal Calibration
◎ Using Databases/Count Weighing/Check Weighing
◎ Percentage Weighing/Density/statistics Function
◎ Textile/Animal Weighing/Peak Hold
◎ Recipe Function/GLP Setting/User Setting
◎ Baud Rate is adjustable
◎ Languages: Italian/English/Portuguese/German/French/Spanish/Chinese
Technical Specifications
Working Temperature/Humidity
Air Humidity,non-condensing
Power: input 110-230Vac, 50/60Hz; output 24V 1A
Voltage fluctuation: ±10%
Maximum working height: 4000m
class of pollution: II
Installation Type: II
| Capacity [Max] | 6.2g |
| Readability [d] | 0.001mg(1μg) |
| Tare Range | -6.2g |
| Linearity Deviation | |
| Typical | ±4μg |
| Permissible | ±5μg |
| Repeat Ability(Standard Deviation) | |
| Typical(@ 10% MAX) | 1μg |
| Typical(@ MAX) | 2μg |
| Permissible(@ 10% MAX) | 1.2μg |
| Permissible(@ MAX) | 2.4μg |
| Minimum Weight (USP), TYPICAL | 2mg |
| Eccentric Load Deviation(Test Weight 2g) | |
| Typical | 5μg |
| Weighing Chamber | |
| Opening | Manual |
| External Dimensions | 160mm |
| Internal Dimensions | 130mm |
| Weighing Pan Dimensions | 30mm |
| Calibration Method | Internal Automatic |
| Stabilization Time | ≤10sec |
| Display | 5'' Color Touch Screen |
| Interfaces | RS232, USB |
| Sensitivity Drift Between +10°C and +30°C | 1ppm /°C |
| Operating Temperature | +10°C, +40°C |
| Operating Temperature Change Rate | ±0,4°C/1h (±1,3°C/8h) |
| Relative Humidity | 40%, 80% |
| Relative Humidity Change Rate | ±1%/h (±5%/8h) |
